Düchting Type MC

Horizontal single-stage centrifugal pump in back pullout design.
  • Pumping of abrasive and corrosive liquids
  • All components which are in contact with the liquid are made of SICcast®
  • Suction flange: Axial
  • Discharge flange: Top (Vertical)
  • Closed impeller with three-dimensionally curved vanes
  • Impeller is key driven; reverse rotation (e.g. back-flushing) is possible
  • Re-adjustable inclined gap between impeller and volute casing to optimize the efficiency and differential pressure after longer operation
  • Single acting, metal free mechanical seal DÜTEC® with springs located outside of the liquid (other seal types available)
  • Oil-lubricated antifriction bearings
  • Back pullout design (the complete rotating assembly can be removed while the casing remains on its position)
  • In many applications the wear life of SICcast® greatly exceeds convential materials
  • Available with heavy-duty bearing units for extreme applications
  • Optimized design ensures easy maintenance and long service life even under difficult conditions.

Pump Size:            1 1/4" to 12" (DN 32 to DN 300)
max. Pressure:    150 PSI (10 bar)
max. Flow:            6600 gpm (1500 m³/h)
Total head:           up to 300 ft (90 m)
Rotating speed:   to 3600 rpm

Pumping of abrasive and corrosive media:
  • Flue gas desulfurization
  • Incinerators
  • Pigment industry
  • Chem. industry
  • Water treatment
  • Seawater desalination plants
  • Fertilizer industry / Potash industry

Spiral casing:  SICcast®Impeller:SICcast®Shaft:1.4462Mechanical seal: Silicon carbide (SiC)
